- Cable construction (inner- to outer-most):
- Core:
- 14 AWG / Ø1.63mm
- CCS (Copper Coated Steel) 21%
- DC Resistance: 11Ω / 1000ft. at 20°C
- Dielectric Foam PE: Ø7.11mm
- Shielding:
- Bonded Aluminium Foil
- Braid Aluminium Shield:
- 96x Ø0.16mm,
- 60% Coverage
- Non-bonded Aluminium Foil
- Braid Aluminium Shield:
- 64x Ø0.16mm,
- 40% Coverage
- Shield DC Resitance: 6.9Ω / 1000ft. at 20°C
- PVC Jacket:
- Operating temperature range: -20 ~ 60°C
- Return loss: 15dB Max (100% swept tested)
- Impedance: 75.0Ω ± 3Ω
- Attenuation:
- 0.20dB/100ft @ 1MHz
- 0.50dB/100ft @ 10MHz
- 0.95dB/100ft @ 50MHz
- 1.25dB/100ft @ 100MHz
- 1.75dB/100ft @ 200MHz
- 2.45dB/100ft @ 400MHz
- 3.35dB/100ft @ 700MHz
- 3.8dB/100ft @ 900MHz
- 4.00dB/100ft @ 1000MHz
- 4.40dB/100ft @ 1200MHz
- 4.80dB/100ft @ 1450MHz
- 5.30dB/100ft @ 1800MHz
- 5.80dB/100ft @ 2200MHz
