DP SERIES
LIGHT ON WEIGHT. HEAVY ON POWER.
SPECIFICATIONS
| Model | DP-4030 | |
|---|---|---|
| Rated Power | 8 Ω / Stereo | 4 x 300 W |
| (THD=1%, | 4 Ω / Stereo | 4 x 450 W |
| Each chan works simultaneously with continuous sinusoidal 1 KHz) |
2 Ω / Stereo | – |
| 16 Ω / Bridge | 2 x 600 W | |
| 8 Ω / Bridge | 2 x 900 W | |
| 4 Ω / Bridge | – | |
| 100 V Hi-Z | – | |
| 70 V Hi-Z | – | |
| Output RMS voltage | 49.0 V | |
| Max Input Level | 8.7 Vrms (+21 dBu)(Default Gain) | |
| Default Gain (Rated Power,1 KHz) |
35 dB | |
| Gain (Rated Power,1 KHz) | 35 dB or 32 dB | |
| THD+N | Typical value:0.05% (10% Rated Power,8 Ω) | |
| Cross-Talk | Typical: 75 dB (Below Rated Power,20 Hz-1 KHz,8 Ω) |
|
| Frequency Response | Typical value:+0,-0.5 dB (10% Rated Power,20 Hz-20 KHz,8 Ω) | |
| Input Impedance | 20 kΩ (Balanced), 10 kΩ (Unbalanced) | |
| Damping Factor | Typical: 300 (20 Hz-200 Hz,8 Ω) | |
| SNR | Typical:100 dB (A weighted, 20 Hz-20 KHz,8 Ω) |
|
| Main Power | 100-240 VAC ±10%, 50/60 Hz |
|
| Protection | Over temp limit Overload and DC protection |
|
| Size(W×H×D) mm | 480 x 45 x 297 | |
| Net Weight | 4.5 Kg |
