$279.00
Compliance with the 802.3af/at PoE+ standard supports up to 30W on each PoE port. The total 250W PoE power budget for the 16 × gigabit PoE+ ports makes it suitable for a wide range of applications, from surveillance to networking in offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and etc.
Ensures smooth traffic for latency sensitive applications, such as voice and video, by designating the priority of traffic based on Quality of Service (QoS).
When your total power consumption exceeds 250W, Intelligent Power Management automatically cuts lower priority ports’ power to ensure high-priority ports’ power supply. This protects the device from power overload operation. It also automatically detects the required PoE power for your device and protects your non-PoE equipment from being damaged.
Durable metal casing and professional heat dissipation design ensure the wide operating temperature (0°C ~ 50°C) with reliability.
The TL-SG1218MP is fully compatible with PoE devices, such as IP cameras, access points, and IP phones. It also works with non-PoE wired devices to provide gigabit connections, such as PCs, printers, and IPTV.
| HARDWARE FEATURES | Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab,IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p |
|---|---|---|
| Interface |
|
|
| Network Media |
|
|
| Fan Quantity | 2 | |
| Physical Security Lock | Yes | |
| Power Supply | 100V-240V AC, 50/60Hz | |
| PoE+ Ports(RJ45) |
|
|
| Dimensions (W×D×H) | 440mm × 180mm × 44mm (17.3″ × 7.1″ × 1.73″) | |
| Mounting | Rack Mountable | |
| Max Power Consumption |
|
|
| Max Heat Dissipation |
|
|
| PERFORMANCE | Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.78 Mbps | |
| MAC Address Table | 8K | |
| Packet Buffer Memory | 4.1 Mbit | |
| Advanced Functions |
|
|
| Jumbo Frame | 10KB | |
| ENVIRONMENT | Operating Temperature | 0°C ~ 50°C (32°F ~ 122°F) |
| Storage Temperature | −40°C ~ 70°C (−40°F ~ 158°F) | |
| Operating Humidity | 10~90% RH non-condensing | |
| Storage Humidity | 5~90% RH non-condensing | |
| OTHERS | Certification | CE, FCC, RoHS |
| Package Contents |
|
