MC200CM GIGABIT ETHERNET MEDIA CONVERT SC MULTI-MODE UPTO 550M TP-LINK MC200CM

$49.00

MC200CM TP-LINK Gigabit Ethernet Media Converter (SC, multi-mode) Extends Up to 550 meters

The MC200CM is a media converter designed to convert 1000BASE-SX fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX standards, the MC200CM is designed for use with multi-mode fiber cable utilising the SC-Type connector. The MC200CM supports shortwave (SX) laser specification at a full wire speed forwarding rate. It works at 850nm on both transmitting and receiving data.

Features

Works at 1000Mbps in Full-Duplex mode for both TX port and FX port
Supports auto MDI/MDIX for TX port
Provides switch configuration of Force / Auto transfer mode for FX port
Extends fiber distance up to 0.5km
Easy-to-view LED indicators provide status to monitornetwork activity easily
External power supply

SPECIFICATIONS

Standards and Protocols	IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x
Basic Function	Full Duplex Flow Control (IEEE 802.3x) Extends fiber distance up to 0.5km using 50/125umfiber Extends fiber distance up to 0.22km using 62.5/125um fiber
Ports	1 × 1000M SC port 1 × 1000M RJ45 port (Auto MDI/MDIX)
Wave Length	850nm
Network Media 1000BASE-FX	Multi-mode Fiber
Network Media 1000BASE-T	UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100 ohm STP (maximum 100m)
LED Indicators	PWR, LINK, RX
Dimensions (WxDxH)	94.5mm × 73.0mm × 27.0mm (3.7″ × 2.9″ × 1.1″)
Power Supply	External Power Adapter
Safety & Emission	FCC, CE, RoH
Environment	Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: −40°C ~ 70°C (−40°F ~ 158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing
