Nano Size World's Smallest No matter if you are adding Bluetooth 5 to your desktop or laptop, you can expect to plug and forget, thanks to its ultra-small nano-sized housing.
Bluetooth 5.0 The Latest Performance StandardSpeed, distance and connectivity set the new Bluetooth 5.0 apart from the older generation. Gain faster transfer speeds of up to 3 times (3Mbps with Enhanced Data Rate) and extended distance of up to 4 times that of Bluetooth 4.0 (40 Meters Indoor).
Make it Wireless | Connect Your Devices There are a lot of products with Bluetooth built-in, yet youcan't fully utilize those products because your machine doesnot have Bluetooth connectivity. You can now connect Bluetooth enabled devices such as controllers, headphones, speakers, keyboards and mouse, printers, smartphones, tablets and more.
Bluetooth BLE | Keeping the Energy Consumption Low Supports Bluetooth Low Energy (BLE), meaning that your devices are connected with optimal energy consumption. Real
Bluetooth 5.0 | BQB CertifiedThe BT-8500 Bluetooth 5.0 Nano USB Adapter is qualified with BQB certification. The Bluetooth logo is onlyavailable for products that passed the Bluetooth qualification process and earned the BQB certification.
{tab Specifications}
| HARDWARE | |
| Interface | •1 x USB 2.0 Type A |
| Antenna | •Internal PiFa Antennas x 1 |
| Dimensions | •7.1 (H) x 14.9 (W) x 17.4 (D) mm |
| Weight | •2g |
| BLUETOOTH | |
| Standards | •Bluetooth 5 specification compliant |
| Frequency Band | •2402~2480MHz |
| Maximum Data Speed | •3Mbps (class BT-BR/EDR) : 2Mbps(BLE) |
| Output Power | •8dB (max.) |
| Receiver Sensitivity | 94dBm (2Mbps EDR) 87dBm (3Mbps EDR) 98dBm (BLE) 06dBm (125K BLE long range) |
| OTHERS | |
| Certification | •CE, FCC, NCC, BSMI, BQB |
| Environmental Condition | •Operating Temperature: 32~104°F (0~40°C) •Storage Temperature: -4~140°F (-20~60°C) •Operating Humidity: 10~90% (NonCondensing) •Storage Humidity: Max. 95% (NonCondensing) |
| System Requirement | •Windows 8.1/10 32bit/64bit or above •Linux: Kernel 2.6.32 - 5.3 or above (support Fedora & Ubuntu only) |
| Installation | •Easy setupwizard with auto run configuration |
| Package Content | •Bluetooth 5.0 USB Adapter •Quick Installation Guide |
