UAP-AC-HD UNIFI AC2600 ACCESS POINT DUAL BAND 1733+800 MBPS UBIQUITI NHU-UAP-AC-HD

Online Stock Only.

For "click and collect" orders at Lynbrook store the shipping fee will still apply on collection for items not stocked at the Lynbrook store.

Ubiquiti UniFi AP AC HD Access Point

Build your Wi-Fi network with the UniFi® AC HD Access Point, part of the Ubiquiti Networks® UniFi Enterprise Wi-Fi System. The UAP-AC-HD, is an indoor/outdoor, high-performance, 802.11AC Wave 2 dual-band access point, capable of throughput speeds of up to 2533 Mbps and a maximum range of up to 122 meters. Engineered from the ground up to take advantage of 802.11AC Wave 2, the UAP-AC-HD provides unparalleled multi-user support.
High-Density Applications Powered by MU-MIMO Technology
802.11ac Wave 2 MU-MIMO (Multi-User, Multiple Input, Multiple Output) technology allows a Wave 2 AP to communicate with multiple clients at the same time – significantly increasing multi-user throughput and overall user experience.

  • Radio Hardware Acceleration. Independent 2.4 GHz and 5 GHz dedicated hardware offload for maximized multi-user throughput and reduced latency
  • CPU Hardware Acceleration. Dedicatedhardware offload for QoS, Guest Control, and Client Management
  • Optimized for MU-MIMO. Genetically optimized antenna arrays for maximal utilization of 802.11ac Wave 2 MU-MIMO Beamforming
  • Beamforming. Data is sent and received using multiple antennas to increase throughput and range.

Advanced Features in UniFi Controller
UniFi is quickly expanding to a full Software Defined Networking (SDN) solution with seamless integration of high-performance switching, gateways, and more.

Specifications

UNIFI
Dimensions 220 x 220 x 48.1 mm
Weight 700 g (24.7 oz), 830 g (29.3 oz) with Mounting Kits
Networking Interface (2) 10/100/1000 Ethernet Ports
Ports (2) Ethernet RJ45, (1) USB Type C
Buttons Reset
Antennas (2) 2.4G internal single band antennas, dual polarity (2) 5G internal single band antennas, dual polarity
Wi-Fi Standards 802.11a/b/g/n/ac/ac-wave2
Power Method PoE 802.3at
Power Supply PoE Injector 48VDC -0.5A Gigabit
Maximum Power Consumption 17W
Max TX Power 25 dBm
BSSID 4 Per Radio
Power Save Supported
Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
Certifications CE, FCC, IC
Mounting Wall/Ceiling (Kits Included)
Operating Temperature -10 to 70°C (14 to 158° F)
Operating Humidity 5 to 95% Noncondensing
ADVANCED TRAFFIC MANAGEMENT
VLAN 802.1Q
Advanced QoS Per-User Rate Limiting
Guest Traffic Isolation Supported
WMM Supported
Concurrent Clients 500+
SUPPORTED DATA RATES (MBPS)
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 450 Mbps (MCS0 - MCS23, HT 20/40)
802.11ac 6.5 Mbps to 1.7Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80)
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Model Comparison

UAP-AC-PRO UAP-AC-HD
Dimensions Ø196.7 x 35 mm Ø220 x 48.1 mm
Environment Indoor/Outdoor Indoor/Outdoor
2.4 GHz Radio Rate 450 Mbps 800 Mbps
5 GHzRadio Rate 1300 Mbps 1733 Mbps
PoE Mode 802.3af PoE/802.3at PoE+ 802.3at PoE+
Ports (2) 10/100/1000 Ethernet (2) 10/100/1000 Ethernet
Wi-FiUsers 200 Users 500+ Users
