U6-LR WIFI 6 LONG RANGE ACCESS POINT UNIFI UBIQUITI NHU-U6-LR

Online Stock Only.

For "click and collect" orders at Lynbrook store the shipping fee will still apply on collection for items not stocked at the Lynbrook store.

{tab Features}

Ubiquiti UniFi Wi-Fi 6 Long-Range AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4GHz @ 600Mbps & 5GHz @ 2.4Gbps **No POE Injector Included**

U6-LR is a high-performance Access Point leveraging advanced WiFi 6 technology to provide powerful wireless coverage to enterprise environments.It delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz 4x4 MIMO radios. The U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor and semi-outdoor environments (IP54 rated).

Features:

  • 1.3 GHz dual-core processor (now upgraded to support full-duplex 1 Gbps TCP/IP performance)
  • Four-stream high-efficiency Wi-Fi 6 technology
  • 5 GHz band 4x4 MU-MIMO and OFDMA with radio rate of 2.4 Gbps
  • 2.4 GHz band 4x4 MIMO with radio rate of 600 Mbps
  • Powered with 802.3at PoE (PoE injector not included)
{tab Specifications}
Mechanical
Dimensions

Ø220 x 48mm (Ø8.66 x 1.89")

Weight

Without Mount: 800 g (1.76 lb)
With Mount: 930 g (2.05 lb)

Enclosure Material

Plastic

Mount Material

SGCC Steel

Weatherproofing

IP54

Hardware
Processor Specs

Dual-Core®Cortex®A53 at 1.35 GHz

Memory Information

512 MB

Management Interface

Ethernet

Bluetooth Low Energy 5.0

Networking Interface

(1) 1 Gbps Ethernet RJ45

Button

Factory Reset

LED

RGB

Power Method

PoE+, Passive PoE (48V)

Power Supply

UniFi PoE Switch
48V, 0.5A PoEAdapter (Not Included)

Supported Voltage Range

44 to 57VDC

Max. Power Consumption

16.5W

Max. TX Power
2.4 GHz 26 dBm
5 GHz 26 dBm
MIMO
2.4 GHz 4 x 4
5 GHz 4 x 4
Throughput Speeds
2.4 GHz 600 Mbps
5 GHz 2400 Mbps
Antenna Gain
2.4 GHz 4 dBi
5 GHz 5.5 dBi
Mounting

Wall/Ceiling (Kits Included)

Operating Temperature

-30to 60°C (-22 to 140° F)

Operating Humidity

5 - 95% Noncondensing

Certifications

CE, FCC, IC

Software
Wi-Fi Standards

802.11a/b/g
Wi-Fi 4/Wi-Fi 5/Wi-Fi 6

Wireless Security

WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3*)

*Supported With Upcoming Controller Versions

BSSID

8 per Radio

VLAN

802.1Q

Advanced QoS

Per-User Rate Limiting

Guest Traffic Isolation

Supported

Concurrent Clients

300+

Supported Data Rates (Mbps)
802.11a

6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b

1, 2, 5.5, 11 Mbps

802.11g

6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (Wi-Fi 4)

6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)

802.11ac (Wi-Fi 5)

6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)

802.11ax (Wi-Fi 6)

7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)

{/tabs}
