T6600 600V 200A AC/DC MULTI TESTER WITH FIELDSENSE TECHNOLOGY FLUKE T6-600

$572.75

Overview

T6600 600V 200AMP AC/DC MULTI TESTER WITH FIELDSENSE TECHNOLOGY

Measure voltage without test leads

Measure voltage up to 600 V ac through the open fork, without test lead contact to live voltage.+ Without opening covers or removing wire nuts. On wires up to AWG 4/0 (120 mm2), carrying as much as 200 A. It will change your job. Safer. Faster. Easier.

Features

FieldSense technology for ac voltage, current and frequency measurement without making electrical contact to live voltage+
1 to 600 V ac
0.1 to 200 A ac
Resistance 1 ? to 2000 ?
Works with wires up to AWG 4/0 (120 mm2) with a 17.8 mm jaw opening
HOLD button temporarily freezes the reading for easy viewing
Easy to read display with backlight
Accepts optional Fluke TPAK Magnetic Meter Hanger for convenient operation
Standard two-year warranty; extendable to 4 years

Specifications

Measurement Specifications
Function	Requires test leads	Range	Resolution	Accuracy^[1]
FieldSense ac voltage	No	600 V	1 V	±(3% + 3 counts) 45 Hz - 66 Hz^[2][3]
FieldSense ac current	No	200.0 A	0.1 A	±(3% + 3 counts) 45 Hz - 66 Hz
FieldSense frequency (Hz)	No		1 Hz	±(1% + 2 counts)^[3]
Volts ac	Yes	600 V	1 V	±(1.5% + 2 counts) 45 Hz - 66 Hz
Volts dc	Yes	600 V	1 V	±(1% + 2 counts)
Resistance	Yes	2000 ?	1 ?	±(1% + 2 counts)
Safety		600 V CAT III
Accuracy^[1]: ± ( [ % of reading] + [number of least significant digits] ). Accuracy is specified for 1 year after calibration, at 18 °C to 28 °C (64 °F to 82 °F) with relative humidity to 90 %. AC measurements are ac-coupled, RMS responding. Accuracy^[2]: Add 3 % without an external ground connection. External ground connection required for user wearing insulated gloves, standing on an insulated ladder, or otherwise insulated from earth ground. Accuracy^[3]: FieldSense is specified from 16 V to 100 % of range.

General Specifications
Calibration	1-year calibration cycle
Dimensions	61.1 x 259.3 x 43.8 mm
Jaw opening	17.8 mm
Weight	0.35 kg (0.78 lb)
Temperature Operating: Storage:	-10 °C to +50 °C (14 °F to 122 °F) -30 °C to +60 °C (-22 °F to +140 °F)
Altitude Operating: Storage:	2,000m (6,562 feet) 10,000 m (32,808 feet)
Relative Humidity	0% to 90%, 5 °C to 30 °C (41 °F to 86 °F) 0% to 75%, 30°C to 40 °C (86 °F to 104 °F) 0% to 45%, 40°C to 50 °C (104 °F to 122 °F)
Battery Type and Life	2 x AA (IEC LR6); 360 hours continuous, typical; 200 hours using FieldSense
Temperature coefficient	0.1 x (specified accuracy) / °C for <18°C or >28 °C (< 64.4 °F or > 82.4 °F)
Safety	IEC/EN 61010-1: Pollution Degree 2
Electromagnetic Environment	IEC/EN 61326-1: Portable
