Sold Out
Please note this new 5MP feature is compatible with DOSS HBD16DVRV3 only. Due to the limitation of the DVR hardware, it is not compatible with DOSS HBD4DVRV3 and HBD8DVRV3 at this stage. Refer to FAQ how to set it up. However you can use it as normal 700TVL analog camera, whichis compatible with other DVR
| Sensor | 1/2.7" 5 Mega pixels CMOS |
| Effective pixels | 2592(H) x 1944(V) |
| Video frame rate | 2560x1440@25/30fps;2592x1944@20fps/12.5fps |
| Resolution | 1280H (CVBS output) |
| Min. Illumination | Color: 0.1 Lux/F1.2, B/W: 0.01 Lux/F1.2 |
| Lens | 3.7mm pinhole lens |
| Sync System | 7 |
| Electronic Shutter | Auto/ Manual (X30~1/50000) / FLK |
| S/N Rate | =50db(AGC OFF) |
| Video output | 1.0Vp-p complex video output, 75O |
| Output model | PAL/NTSC adjustable |
| OSD menu | |
| White balance | ATW/AWC-SET/INDOOR/OUTDOOR/MANUAL/AWB |
| NR | 2DNR/3DNR, OFF |
| Image adjustable | Brightness, sharpness, AGC |
| DWDR | AUTO/ON/ OFF |
| Sens-up | OFF/ Auto (X30, X25, X20, X15, X10, X8, X6, X4, X2) |
| BLC | BLC/ HLC/ OFF |
| AGC | Auto |
| Day&night switch | Auto, EXT, B/W, Color |
| Privacy mask | / |
| Motion detection | / |
| Mirror | Horizontal/ vertical/ rotation |
| Lens shading compensation | OFF/ON |
| DPC | Auto,/B/W |
| Defog | OFF/ Auto |
| OSD menu | Chinese, English and so on 12 languages |
| Output mode | CVBS 1280H/AHD 4M/AHD 5M/CHD 4M/THD 4M/THD 5M |
| GENERAL | |
| Transmission distance | 75-3/300m,75-5/500m |
| Operating temperature | -10°C ~ 55°C |
| Operating humidity | 0%-90% |
| Power consumption | =2w |
| Power supply | DC12V |
| Dimensions(mm) | 43(W)*43(H)*15(L)mm |
| Weight/PCS(g) | 150g |
Go to System Setting, then Device Setting, change the Display Mode to one of the 8 Analog (2592x1944) options.
Please Note: Online stock only for this item. Shipping at checkout for this item may be an estimate only and may apply only to some metro areas or to a specific distance from supply location. Local pickup may be available on some items by prior arrangement. Shipping charges may still apply for this item for Click and collect in store orders as this item may still need to be shipped to us for collection from the local pickup location.
Please use the contact us form to get an accurate shipping quote based on your order quantity and location to avoid order cancellation charges.
