MX44VWC HDMI 4K 4X4 SEAMLESS MATRIX MULTIVIEWER VIDEO WALL CONTROL PRO2 SMX46
MX44VWC HDMI 4K 4X4 SEAMLESS MATRIX MULTIVIEWER VIDEO WALL CONTROL PRO2 SMX46
Sold Out$1,195.00
Seamless 4K HDMI 4x4 matrix switch & Video wall controller
Features
Seamless HDMI 4X4 matrix mode
Seamless switching ensures no delay during transitions, with the switching speed less than 40 millisecond
Support video wall mode and mirror video wall mode, an option of the horizontal or vertical mirror
10 preset scenes for both video wall and mirror video wall mode
Option to choose 1 source to 1 display or 1 source to 2-4 displays under video wall mode
Any four of the outputs can be turned off individually
Video preview demo mode with preset time options of 2S, 5S, 10S, 30S, 60S.
Multiviewer mode
180-degree clockwise rotation plus crop or zoom feature
Support PCM 2CH audio
Support EDID management
Compliant HDCP 2.2 and HDCP1.4
Support high definition resolutions including 4K30HZ,1080p@60Hz@36 b/pixels, and other standard video formats
Support output downscale to 1080P/720P/2560*1440/1920*1200/1360*768
Control the matrix with the front panel button, remote control, RS232, web control, or third-party platform
The command list is available to integrate with the third-party platform
1U rack design, easy installation
Micro USB port for future firmware upgradeable
Please note: unit supports 4K@30hz output only, if 4K@60hz signal comes in, it will auto downscale to 1080P instead, however it will pass through the 4K@30Hz signal.
Specifications
Operating Temperature Range: 0 to +40°C (32 to +104°F)
Operating Humidity Range: 5 to 90 % RH (no condensation)
Input Video Signal: 0.5-1.0 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
Video Format Supported: DTV/HDTV: 1080P/1080i/720P/576P/480P/4K
