The IXW-MA is a multi-purpose adaptor for the IX Serieswith 4 contact inputs and 10 relay outputs.
The inputs on the IXW-MA can be used to send a command to a specific station to perform a task.
The IXW-MA relays are associated to a specific station and programmed to change state when relay output 1 or 2 on the associated station changes state.
The IXW-MA is a PoE device, and can be programmed via IX Series Support Tool 5.0 or later.
Power Source: 802.3af PoE compliant
Power Draw: Standby: 43 mA; Maximum: 135 mA
Relay Output: Relays 1-4: Form C 24V AC/DC 500mA - Relays 5-10: Form A 24V AC/DC 500mA
LAN: Ethernet (10BASE-T, 100BASE-TX)
Protocols: IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
Encryption system: TLS1.0, TLS1.1, TLS1.2
Port Security: IEEE 802.1X
Dimensions: 7-1/2" x 9-5/8" x 13/16"
