Sold Out
Online Stock Only.
For "click and collect" orders at Lynbrook store the shipping fee will still apply on collection for items not stocked at the Lynbrook store.
{tab Features}
*Power Supply included but not required
The product has been tested without a power supply to a total distance of 30m using quality Pro2 leads.
By adding a power supply, signal can be boosted. If higher loss HDMI leads are used or long distances are required, we recommend using the power supply.
{tab Package Contents}| Operating Temperature Range | -5 to +35°C (+23 to +95°F) |
| Operating Humidity Range | 5 to 90%RH (No Condensation) |
| Input Video Signal | 0.5-1.0 VoltsP-P |
| Input DDC & Signal | 5 volts p-p(TTL) |
| Video format | 1080P / 1080i / 720P / 576P / 576i / 480P / 480i / 3D Video |
| Video Colour Format | xvYCC / Deep Colour (10/12-bit) |
| Support AudioFormat | DTS-HD MasterAudio / Dolby True-HD / etc |
| Output Video | HDMI 1.3 / HDCP 1.2 |
| Data transferspeed rate | 6.75Gbps (Maximum) |
| Power consumption | 4 Watts (Maximum) |
| Transmission Distance | 15 metres (Maximum) |
| Dimension (L×W×H) | 115 × 62 × 25mm |
| Net Weight | 212g |
| Gross Weight | 520g |
Q. Why is my remote not switching between sources?
A. The HDMI5SM will only switch between active HDMI inputs. IF the HDMI source (eg. Bluray player) is off or in stand-by, it will not be recognised by the HDMI switch as an input.
