$80.00
Pro2's high quality HDMI splitters take a single input— Blu-ray, HD TV, PayTV (Foxtel), Xbox, PlayStation etc. — and split them to multiple outputs without any signal loss. This state of the art 4K HDMI 2.0 UHD splitter is capable of displaying resolutions up to 3840 x 2160 and is also ideal for today's 1080p 3D signals and is future proofed for many years to come.
Our range provides an ideal solution from a simple home scenario to a massive 8 monitor commercial installation. Allmodels are built to last, constructed with a solid and robust metal casing. The Pro2 HDMI splitters are also powered, meaning they can help extend your cable runs by equalising your signals and re-clocking them before passing them onto the displays.
With their built-in EDID feature, our range of splitters will automatically downscale any 4K signal to 1080p if the display attached to the port can only handle 1080p without affecting any 4K capable display! This feature makes them pretty unique in the market.
| Model | HDMI2SPV2 | HDMI4SPV2 | HDMI8SPV2 | ||
|---|---|---|---|---|---|
| Code | 64510014 | 64510024 | 64510034 | ||
| Description | 2 WAY SPLITTER | 4 WAY SPLITTER | 8WAY SPLITTER | ||
| HDMI Inputs | 1 | ||||
| HDMI Outputs | 2 | 4 | 8 | ||
| 3DSupport |  | ||||
| 4K x 2K | | ||||
| HDCP Compliance | v2.2 | ||||
| HDMI Resolutions | 480p / 720p / 1080i / 1080p @ 60 Hz / 4K x 2K @ 24 Hz | ||||
| Audio Formats | LPCM /Dolby-AC3 / DTS 7.1 / DSD | ||||
| Data Transfer Speed | 18 Gbps | ||||
| Input Video signal | 5.0 Volts P-P (TTL) Single Link | ||||
| Video Amplifier Bandwidth | 140 MHz | ||||
| Transmission Distance | 15 metres using standard 26AWGcable | ||||
| Power Supply (included) | 5V 1A DC | ||||
| Dimensions | 93.6 x 61 x 15 mm | 150 x64.2 x 17 mm | 247.2x 110 x 17 mm | ||
| Weight | 120g | 245g | 610g | ||
| Power Consumption | 1 W | 2 W | 5 W | ||
| Operating Temp. Range | -15°C to 55°C (23°F to 95°F) | ||||
| Operating Humidity Range | 5 to 90% RH (no condensation) | ||||
