HD4002DM QUAD INPUT HD MODULATOR DVB-T MPEG2/4 RESILINX RESI-LINX

Overview

HD-4002DM Professional Digital Modulator

Quad Input High Definition DVB-T MPEG-2/4

The HD-4002DM is a Quad Input High Definition DVB-T Professional Commercial Modulator.

Dual mode DVB-T distribution with both MPEG-2 / AVC (MPEG-4) encoding – along with IP Streaming available in the one product – ensuring the product is compatible with all HD TVs.

Up to 1080P HD Distribution: 576i / 720p / 1080i / 1080p (AVC only).

Features:

• Quad Input High Definition DVB-T Modulator that converts HD video and audio signals to digital COFDM DVB-T Channel.
• Dual Mode: MPEG-2 & AVC (MPEG-4) Encoding.
• Simulcastng IP Multicast Broadcasting.
• Distributes 576i / 720p / 1080i / 1080p picture quality (1080p only available on AVC).
• Programmable Channel, Network Names and LCN.
• HDMI, Component, CVBS, Analogue Audio, Digital Coaxial/Optical inputs.
• 43dB MER.
• Full function front LCD display for adjustments.
• Web management for easy programming and monitoring.
• 2K/8K Carriers.
• Adjustable VHF / UHF Output (6-69).
• Adjustable attenuation (98dB launch).
• Desk, wall and rack mountable.
