HA01 4K HDMI AUDIO EXTRACTOR SPDIF STEREO PRO2 HC01

FEATURES

  • Extract and duplicate the digital HDMI audio signal from the HDMI input to 2 channel analog stereo output or 5.1 channel Audio output
  • Supports resolution up to 4K@30Hz
  • Supports deep color up to 36bit
  • Support 3D
  • Three Audio EDID Settings: 2.0CH/5.1CH/By pass
  • Supports Apple TV and various Blu-ray player, satellite receivers



NOTES:There is still audio from the HDMI output.



SPECIFICATIONS


Operating Temperature Range

-5 to +35?(+23 to +95?)

Operating Humidity Range

5 to 90%RH (No Condensation)

Input Video Signal

0.5-1.0 Volts P-P

Input DDC Signal

5 volts p-p(TTL)

Support Video format

4Kx2K/1080P/1080i/720P/576P/576i/480P/480i
3D video

Support Video Color Format

xv-YCC/deep color 36bit

Support Audio Format

DTS-HD Master Audio?Dolby true-HD etc.

Data transfer speed rate

10.2Gbps(Maximum)

Power consumption

3watts(Maximum)

Dimension (LxWxH)

89.2x66.7x25mm

Net Weight

175g
