Specifications:
Photometrics
Light Source: 180W LED White
Beam Angle: : : 1.8°
Output: 191,301 lux @ 5m at 1.8°
CCT: 7,000K
CRI: >70
Led lifespan: > 20,000 hours
Colour
14 Colour + Open (first wheel)
8 Colour + Open (second wheel)
Gobos
Fixed: 10 + Open
Rotating: 4 + Open
Gobo Shaking: Yes
Gobo Indexing: Yes
Effects
Dimming: 0~100%
Strobe: 1 - 25 Hz
Focus: Motorised
Prism(1): 24-Facet circular prism, (Optional Rainbow Effect)
Prism(2): 5-Facet linear prism, indexing
Prism Overlap: Yes
Frost: Yes
Movement
16 bit resolution
Auto repositioning
Pan: 540°
Tilt: 270°
Power
Max power consumption: 260W
Input Voltage: 100~240V AC, 50/60Hz
Connection: True1 in/out
Control
Control Protocol: DMX512, RDM
Optional Wireless
DMX Channels: 20 / 23
Interface: 3-pin/5-pin XLR (in/out)
Display: TFT control panel
Housing
Materials: ABS & Steel, matte black finish
Protection: High temperature automatic protection
IP rating: IP65
Dimensions: 338 x 240 x 555mm
Net Weight: 16.5 kg
