Sunon 24V 80mm X 80mm X 25mm DR MagLev Motor Fan VAPO Bearing
SUNON DR (Dust Resistant) MagLev Motor Fan uses the MagLev technology with new design features to increase dust-resistance and prevent oil leakage.
Features
- Better oil leak prevention. DR MagLev?s one-piece structure with the B&S (Blanked & Seamless) Technology and S&C (Seal & Clip) Design provides the best prevention of oil leakage.
- Better dust-resistance. The innovative S&C (Seal & Clip) Design provides the best resistance to dust invasion.
- Higher reliability. The S&C (Seal & Clip) Design can prevent the stator and impeller from falling offand help reduce noise that is caused by stator and impellermovement after a period of usage. The design greatly improves the life expectancy and the reliability.
- Longer life expectancy. Comparing the life expectancy of DR MagLev Motor design with other bearing systems, the life expectancy of the Precise VAPO bearing performs similar to 2 Ball bearing and therefore meets the customer?s requirements for continuous fan operation.
Model | P/N | Size |
Bearing
| Rating
Voltage
(VDC) | Power
Current
(AMP) | Power
Consumption
(WATTS) | Speed
(RPM) | Air
Flow
(CFM) | Static
Pressure
(Inch-H2O) | Noise
(dBA) | PDF |
ME80252V1-0000-A99 | | 80X80X25 |
| 24 | 0.073 | 1.8 | 3200 | 41 | 0.18 | 33 |
Please Note: Online stock only for this item. Shipping at checkout for this item may be an estimate only and may apply only to some metro areas or to a specific distance from supply location. Local pickup may be available on some items by prior arrangement. Shipping charges may still apply for this item for Click and collect in store orders as this item may still need to be shipped to us for collection from the local pickup location.
Please use the contact us form to get an accurate shipping quote based on your order quantity and location to avoid order cancellation charges.
BALL
VAPO
SLEEVE
