- Double section welded frame structure
- Easy operation and maintaining at the back
- 19” standard installation
- Removable side panels, side locks are optional, easy installing and maintaining
- Cable entry at the top cover and bottom panel
- 120mm fan optional
- Turning angle of front door is above 180 degrees
- Turning angle of rear door is above 90 degrees
Standard:
- Comply with ANSI/EIA RS-310-D, DIN41494 part 1, IEC297-2,
- DIN41494 part 7 standard
Loading capacity:
Material - SPCC cold rolled steel
- Thickness:Mounting profile 1.5mm,others 1.2mm
- Dimensions: 670(W) x 670(D) x 720(H) mm
Understanding our 19” rack mount codes:
XXXXTME800
- The first four digits refer to the height of the 19” rack. 1RU is the equivalent height of 1.75 inches (44.45mm).
- When estimating the overall height, include extra height for the feet / coasters and foam protective material when freighting the item
38RUXXX800
- The next letters generally indicate the style of the door. TMEis a vented metal door. TE is a glass door.
38RUTMEXXX
- The final 3 digits indicate the cabinet depth. Generally you have 600mm or 800mm shelves.
Please Note: Online stock only for this item. Shipping at checkout for this item may be an estimate only and may apply only to some metro areas or to a specific distance from supply location. Local pickup may be available on some items by prior arrangement. Shipping charges may still apply for this item for Click and collect in store orders as this item may still need to be shipped to us for collection from the local pickup location.
Please use the contact us form to get an accurate shipping quote based on your order quantity and location to avoid order cancellation charges.
