6007-3 6007 SERIES 3WAY PLUG AND SOCKET PLASTIC 3 PIN 43576913

Header

Info

• 6007 SERIES CONNECTORS

• There are many special features of the 6007 connector series that exceed standard connector
  design practices.
•  Rated at up to 300V AC/DC, these compact connectors will withstand
  1,500V AC/minute, and operate within a temperature range of -25°C to 105°C.
•  Polarised to ensure correct mating, a positive locking latch also automatically engages at mating, and the
  option exists for in line or hand fitted panel mounted installation.
•  The complete cell housing system fully covers and protects the contacts.
•  The high reliability 2mm O.D. crimp contacts, are easily snappedinto the housings by hand, with two sizes covering a wide wire range from
  0.2 to 2.0mm2.
• Maximum contact resistance is limited to 10 ohm.
